FORGED STEEL GLOBE VALVES

Forged Steel Globe Valves are specifically engineered for accurate throttling and shut-off in High-Pressure and High-Temperature Environments. Ideal for applications in Oil & Gas, Petrochemical, Power Plants, and Refineries, these valves ensure tight shut-off, flow regulation, and long service life in the toughest conditions.

forged steel globe valve

SPECIFICATION
Size Range : ½" to 2" (DN 15 to DN 50)
Pressure Ratings : ASME 800#, 1500#, 2500#
Material Options :
  • Carbon Steel: A105 / A105N
  • Low-Temperature Carbon Steel: LF2
  • Chrome Moly Alloys: F5 / F9 / F11 / F22 / F91
  • Austenitic Stainless Steel: F304 / F304L / F316 / F316L / F347 / F347H / F321 / F321H
  • Duplex & Super Duplex F51 / F53
  • Monel Alloy 20, Inconel, Hastelloy, Bronze, Dual Certified
  • Special Alloys & Custom Materials on request
    • Design Standards : API 602, BS5352, ASME B16.34
    Pressure / Temperature Rating : ASME B16, 34
    Testing & Inspection : API 598, BS6755

    CONSTRUCTION & KEY FEATURES
    Body / Bonnet Types :
  • Bolted Bonnet
  • Welded Bonnet
  • Pressure Seal Bonnet (for high-pressure service)
    • Disc Types :
  • Plug Disc
  • Needle Disc (on request for fine flow control)
    • Stem Design :
  • OS&Y (Outside Screw & Yoke), Rising Stem
    • Body Options :
  • Full Bore, Reduced Bore
    • End Connections:
  • Socket Weld (SW)
  • Screwed (NPT / BSPT)
  • Butt Weld (BW)
  • Flanged Ends (available on request)
    • Operation Options:
  • Handwheel

    • SPECIALIZED APPLICATIONS

    Tailor-made designs for critical operations in:

  • Cryogenic Service (as low as -196°C)
  • Highly Corrosive Fluids with corrosion-resistant alloys or internal coatings

    • Optional testing available for :

  • Low-emission sealing
  • Flow performance
  • Pressure retention and torque analysis

    • Get the Best Globe Valve Price in India Contact us today for a quote or more technical details at info@panchvativalve.com
